D330

Call for Price

2.5-Way Floorstanding Speakers

In the early 1980s, Wharfedale created the blueprint for modern ‘budget’ hi-fi speakers. Almost four decades on, Wharfedale again redefines the low-cost, high-performance speaker concept with the all-new range, the D300 Series.

Running concurrently with the existing Diamond 11 Series, attaining even lower price points, the D300 series has modishly styled enclosures incorporate many similar technologies, re-designed and engineered specifically for this new range. The drive units and bass reflex system are especially noteworthy – no other speaker range delivers such high specifications at such low prices.



SPECIFICATIONS

  • Enclosure type: bass reflex
  • Transducer complement: 2.5-way
  • Bass driver: 5″ (130 mm) black woven Kevlar cone
  • Midrange driver: 5″ (130 mm) black woven Kevlar cone
  • Full range driver: 1″ (25 mm) soft dome
  • Sensitivity (2.83V @ 1m): 88 dB
  • Peak power handling: 25-120 W
  • Peak SPL: 100 dB
  • Nominal impedance: 8Ω compatible
  • Minimum impedance: 4.1Ω
  • Frequency response (+/-3dB): 40Hz ~ 20kHz
  • Bass extension (-6dB): 37Hz
  • Crossover frequency: 3.2kHz
  • Dimension (HxWxD): (940+25) x 200 x (310+28)mm
  • Net weight: 18.2kg/pcs

Brand

Wharfedale
